Introduction of Siraya Tech Resin

1.Siraya Tech resin series

Not sure how to choose the suitable resin for yourself? We'll list all Siraya Tech resin types, properties, uses, and colors here, to help you pick a suitable resin.

Let's have a look at the resin series owned by Siraya Tech.

Resin type Resin name Available colors Link
Castable Resin Cast Purple,True Blue,Royal Blue View Now
ABS-like Resin Fast Grey, Navy Grey, Metal Grey,  Smoky Black, White,Creamy View Now
ABS-like Wear-resistant Resin Fast Mecha White View Now
Drillable Precision Resin Build Sonic Grey, Smoky Black View Now
Water-washable Resin Simple Grey,Clear View Now
Water-washable Resin V2 Simple V2 Grey, Aqua Grey View Now
Tough Resin Blu Clear,Emerald Blue,Osidian Black, Nylon Black, Lava Black View Now
Tough Wear-resistant Resin Blu Mecha White View Now
Tough Model Resin Blu Easy Easy Grey View Now
Flexible Resin Tenacious Clear, Obsidian Black, Flex Black View Now
Flexible Model Resin Tenacious Easy Easy Grey, Easy Navy Grey View Now
Creative Resin Craft Ultra Clear, Glow in Dark Green View Now



2. For new printers' suggestions of resin select

For those new to resin printing, we suggest considering the following aspects when choosing a resin:

  • Good fluidity (low viscosity) which leads to smaller printing tension, easier printing, and higher success rates.
  • Low odor: while resin printing can produce some odor, you can choose low-odor resins to help you adjust as you begin printing.
  • Washable resins: these resins are usually lower in viscosity, making them easier to post-process and more cost-effective.

(Note: It is recommended to print in a well-ventilated and separate room and take personal protection measures. )

Novices recommend trying Siraya Tech resin: Simple water-washable resin, Easy resin, and Fast ABS-like resin.

3.Characteristics of each resin

  • Fast ABS-like resin

This Fast ABS-Like resin has a wide range of applications, from tabletop models to industrial parts, especially suitable for small and half-length models. We have developed a total of 7 colors, they are Grey, Navy Grey, Green, Creamy, White, Smoky Black and new friend Mecha White.

abs like  resin fast printing resin

We would recommend Grey, Matal Grey and Navy Grey to you, Grey is great for novice printing and has a high success rate, Navy Grey and Metal Grey has very clear details and is especially good for making beautiful desktop prints.

Characteristics: It has properties similar to ABS, low viscosity, not brittle, has a certain drop resistance, and has a wide range of compatibility with LCD and DLP printers, high print success rate, and easy cleaning.

Features of Fast:

Shore Hardness: 75D
Tensile Stress at Break (MPa): 31
IZOD Impact (Notched, J/m): 25
HDT at 0.455 MPa (°C): 65
Elongation at Break (%): 7
Young's Modulus (MPa): 800
Liquid Density (g/cm3): 1.1
Viscosity @ 25°C (77°F): 110

View more data on Fast TDS: https://siraya.tech/pages/TDS

Read the Fast User Guide for printing information:https://siraya.tech/pages/support

  • Simple resin

This simple UV 3d printing resin is more suitable for novices to print simple models and figures. We especially recommend Simple Clear for dyeing creations. We have developed a total of 3 colors, which are Clear, Smoky Black and Grey.

water washable resin

Characteristics: Simple Resin is very easy to clean, only needs 15% alcohol to clean, it is better than water wash, and it has a very low odor. Simple is even easier to print than Fast, not brittle, can withstand damage from accidental falls. Simple can be widely used in LCD and DLP printers and is very friendly to beginners.

Features of Simple:

Shore Hardness: 75D
Tensile Stress at Break (MPa): 25
IZOD Impact (Notched, J/m): 18
HDT at 0.455 MPa (°C): 60
Elongation at Break (%): 4
Young's Modulus (MPa): 650
Liquid Density (g/cm3): 1.1
Viscosity @ 25°C (77°F): 110

View more data on Simple TDS: https://siraya.tech/pages/TDS

Read the Fast User Guide for printing information:https://siraya.tech/pages/support



  • Craft Resin

The Craft – Glow In The Dark resin is ideal for applications that require print to emit light in the darkness, including safety signs and Halloween decorations, as well as any creative print. We have developed two colors of Glow-In-Dark-Green and Ultra Clear.

Glow in dark resinUltra Clear resin

Characteristics: With unique visual effects and material properties, Glow-In-Dark can maintain a luminous effect in the dark for up to 4 hours and can be charged in any light. High resolution, smooth surface, and the pigment settles more slowly than other pigments.

Features of Craft:

Shore Hardness: 84
Tensile Stress at Break (MPa): 43
HDT at 0.455 MPa (°C): 65
Elongation at Break (%): 2.5
Young's Modulus (MPa): 950
Liquid Density (g/cm3): 1.1
Viscosity @ 25°C (77°F): 330

Read the Fast User Guide for printing information:https://siraya.tech/pages/support


  • Cast resin

Cast is especially suitable for jewelry and small parts making, we have purple and True Blue currently.

Siraya Tech Cast - Castable resinSiraya Tech Cast - Castable resin

Characteristics: Wax-based castables burn more easily than non-wax-based castables and use ready-to-use powders, making them easier to work with. Affordable, professionals and beginners can enjoy it without having to spend too much.

Features of Cast:

Liquid Denisty (g/cm3): 1.1
Shrinkage: 6%

View more data on Cast TDS: https://siraya.tech/pages/TDS

Read the User Guide for printing information:https://siraya.tech/pages/support



The following are engineered resins - specially developed for special requirements or mixed printing.

  • Blu Resin

Blu is Siraya Tech's earliest resin. It is used to build CNC printers, fixtures/gigs, brackets, and even mechanical parts. It is also great for mixing into other resins to enhance the performance of prints. We mainly launch Emerald Blue, Clear, Obsidian Black and Nylon Black currently.

Introduction of Siraya Tech Resin

Characteristics: Blu is the perfect combination of hardness and impact resistance, with powerful

and precise high resolution, ideal for making sturdy parts. It is also great for mixing into other resins to enhance the performance of prints. The resin has a high viscosity and it is recommended to print at 25℃.

Features of normal Blu:

Shore Hardness: 85
Tensile Stress at Break (MPa): 50
IZOD Impact (Notched, J/m): 45
HDT at 0.455 MPa (°C): 70
Elongation at Break (%): 32
Young's Modulus (MPa): 1800
Liquid Density (g/cm3): 1.1
Viscosity @ 25°C (77°F): 850

Features of Blu Nylon Black

Shore Hardness: 80
Tensile Stress at Break (MPa): 60
IZOD Impact (Notched, J/m): 53
HDT at 0.455 MPa (°C): 63
Elongation at Break (%): 40
Young's Modulus (MPa): 2000
Liquid Density (g/cm3): 1.1
Viscosity @ 25°C (77°F): 750

View more data on Blu TDS: https://siraya.tech/pages/TDS

Read the Fast User Guide for printing information:https://siraya.tech/pages/support



  • Tenacious Resin

This flexible resin is mainly used for miniature models, making braces, O-rings, washers, tabletop games, mini-game models, swords, etc. We have currently developed two colors which are Clear and Obsidian Black.



Introduction of Siraya Tech Resin

Characteristics: Excellent impact resistance, very flexible when the printed model is thin, Its extremely high toughness allows the printed thin objects to be bent 180°. It is suitable as an additive to reduce the brittleness of other resins and improve the durability of the model.

Features of Tenacious:

Shore Hardness: 65D
Tensile Stress at Break (MPa): 28
IZOD Impact (Notched, J/m): 57
HDT at 0.455 MPa (°C): 55
Elongation at Break (%): 70
Young's Modulus (MPa): 800
Liquid Density (g/cm3): 1.1
Viscosity @ 25°C (77°F): 560

View more data on Tenacious TDS: https://siraya.tech/pages/TDS

Read the Fast User Guide for printing information:https://siraya.tech/pages/support



  • Sculpt Resin

This resin is suitable for printing molds, original production molds (vulcanized rubber process), vacuum forming, etc. We have developed three colors for printers currently, namely Clear, Grey and Ultra White.



Introduction of Siraya Tech Resin

Characteristics: Sculpt has very good temperature resistance, Sculpt Clear and Sculpt Grey have DHT up to 160°C, Sculpt Ultra has HDT up to 220°C, very suitable for vulcanized rubber molding, and Sculpt is optimized for LCD and DLP printers, with smooth Finish and excellent resolution.

Features of Sculpt Clear and Sculpt Grey:

Shore Hardness: 90D
Tensile Stress at Break (MPa): 35
HDT at 0.455 MPa (°C): 160
Elongation at Break (%): 5
Young's Modulus (MPa): 3500
Liquid Density (g/cm3): 1.13
Viscosity @ 25°C (77°F): 650

Features of Sculpt Ultra White:

Shore Hardness: 99D
Tensile Stress at Break (MPa): 31
HDT at 0.455 MPa (°C): 220
Elongation at Break (%): 1
Young's Modulus (MPa): 8000
Liquid Density (g/cm3): 1.4
Viscosity @ 25°C (77°F): 500

View more data on Sculpt TDS: https://siraya.tech/pages/TDS

Read the Fast User Guide for printing information:https://siraya.tech/pages/support



  • Build Resin

Build resins are primarily recommended for making assembled parts, models, and functional parts such as electronic housings, drilling, and knocking. We are currently introducing Sonic Grey and Smoky Black to everyone.



Introduction of Siraya Tech Resin

Characteristics: Builds have high accuracy and resolution and can be tapped to form threaded holes. Not brittle, shrink and warp low, a combination of stiffness and flexibility.

Features of Build:

Shore Hardness: 73D
Tensile Stress at Break (MPa): 33
IZOD Impact (Notched, J/m): 27
HDT at 0.455 MPa (°C): 68
Elongation at Break (%): 8
Young's Modulus (MPa): 850
Liquid Density (g/cm3): 1.1
Viscosity @ 25°C (77°F): 110

View more data on Fast TDS: https://siraya.tech/pages/TDS

Read the Fast User Guide for printing information:https://siraya.tech/pages/support
