1. Introduction: High-Speed Printing Meets High-Performance Materials

Flashforge Adventurer 5M (AD5M) is a high-speed CoreXY 3D printer known for its impressive performance out of the box. But when printing high-performance materials like Siraya Tech PPA (Polyphthalamide), the stock open-frame design falls short due to environmental sensitivity.

In this guide, we’ll walk you through how to upgrade your AD5M with an enclosure and nozzle enhancements to reliably print Siraya Tech PPA filament—unlocking new possibilities for professional and functional parts.

2. Meet the Flashforge Adventurer 5M: Speed with Potential

Key Features:

  • CoreXY motion system for fast, stable printing
  • Print speed up to 600 mm/s
  • Max nozzle temp: 280°C
  • Max bed temp: 110°C
  • Automatic leveling and quick-swap nozzles

While ideal for PLA and PETG, its open-frame design struggles with engineering-grade materials like PPA, which require a stable, high-temperature print environment.

Flashforge adventurer 5M printer unenclosed



3. Why PPA Needs a Stable Print Chamber

Siraya Tech’s PPA is a premium engineering filament known for:

  • High heat resistance
  • Excellent tensile strength and rigidity
  • Chemical resistance

However, it’s sensitive to ambient temperature fluctuations during printing. Common issues without a heated enclosure include:

  • Warping and delamination
  • Poor interlayer adhesion
  • Dimensional inaccuracy

An enclosed, temperature-stable print chamber is essential for optimal PPA performance.

4. How to Add an Enclosure to Adventurer 5M

Flashforge offers an official DIY Enclosure Kit, which includes acrylic panels, screws, and brackets. However, structural parts like hinges and handles must be 3D printed.

Steps We Followed:

  • Get the Enclosure Kit: Includes laser-cut clear panels and hardware.

Get enclosure kit from Flashforge website

enclosure kit - Flashforge adventurer 5M printer
  • Print Frame Parts: Use PETG or PLA-CF for strength and heat resistance. STL files are available on Flashforge’s Wiki.

Download frame parts STL files from Flashforge Wiki here

Frame Parts print with PETG-CF Blakc
Printer frame parts- PETG-CF Blakc
White parts print with PLA White
connect parts - flashforge adventurer 5M fdm printer
  • Assemble the Enclosure: Follow the official guide to mount panels, brackets, and accessories.

Flashforge Adventurer 5M Enclosure setup guidance PDF

Flashforge adventurer 5M printer enclosure vs no enclosure



Once assembled, your AD5M becomes a fully enclosed chamber—ready for PPA.

5. Upgrade Your Nozzle: Why Hardened Steel is a Must

Even unfilled PPA runs hot—close to the AD5M’s 280°C limit. Standard brass nozzles may degrade over time. If you're printing PPA-CF or any fiber-filled filament in the future, hardened steel is essential.

Recommended Upgrade:

Use Flashforge’s quick-swap hardened steel nozzle (0.4mm or 0.6mm) for long-lasting reliability.

6. Printing Siraya Tech PPA: Settings and Results

Material Handling Tip:

PPA is highly hygroscopic. Always dry filament before use!
  • Dry at 80–100°C for 6–8 hours in a filament dryer
  • Store in dry box when not in use
Recommended Print Settings (in enclosed AD5M):
  • Nozzle Temp: 270–280°C
  • Bed Temp: 90–110°C
  • Print Speed: 50–80 mm/s
  • Cooling Fan: OFF
  • Bed Adhesion: PEI bed with PVP glue or brim
  • Retraction: Tune distance and speed to reduce stringing
With these settings, we printed strong, dimensionally accurate PPA parts on our upgraded AD5M.

Flashforge adventurer 5M printer PPA prints

7. Conclusion: Expand Your FDM Capabilities

Flashforge AD5M is a high-speed workhorse—but by adding an enclosure and upgrading to a hardened steel nozzle, you can unlock its true potential with Siraya Tech’s PPA filament. This simple yet powerful mod transforms your machine into an engineering-grade printer capable of handling high-temperature, high-strength materials with ease.

Ready to level up your prints? Upgrade your setup and experience the full power of Siraya Tech PPA on your AD5.

Flashforge adventurer 5M Printer Link

Siraya Tech Fibreheart PPA Filament link

3d fdm printing tips
