In the advancing world of 3D printing, the fusion of top-tier printers and specialized resins is key to groundbreaking creations.
For those who demand excellence and durability in their prints, the combination of Elegoo Saturn 3 Ultra 12K 3D Printer with Siraya Tech's Sculpt Ultra White - 250 ℃ High-Temperature Resistant Resin is a game changer.
Elegoo Saturn 3 Ultra 12K: Precision and Quality Unmatched
Elegoo Saturn 3 Ultra 12K 3D Printer stands out with its 10-inch 12K mono LCD, boasting an exceptional resolution of 11520x5120. This allows for prints with incredible detail and sharpness.
The COB + refractive light source provides uniform, consistent light distribution, resulting in prints with a smooth surface and accurate dimensions.
Key Highlights:
- Generous build volume of 218.88x122.88x250 mm³.
- Linux OS with 4G RAM for efficient file transfer and processing.
- Wi-Fi file transfer capabilities.
- New ACF release film for faster printing speeds up to 150 mm/H.
- Robust all-metal machine body.
- 4-inch HD IPS touch screen for easy operation.
- Voxeldance Tango Slicer offering versatile printing modes.
Why Choose Siraya Tech Sculpt Ultra?
Siraya Tech's Sculpt Ultra White Resin takes 3D printing to new heights with its exceptional high-temperature resistance of up to 250C. Its unique composition, featuring a ceramic composite, offers robust chemical resistance and a low water absorption rate.
Applications:
- Low-run injection molds
- Vacuum forming
- Dental applications
- Artistic sculptures
Key Features:
- Ultra-high HDT of 250°C.
- Compatible with high-performance DLP and a wide range of LCD resin printers.
- Exceptional resolution and matte white finish for reduced post-processing.
This resin is perfect for demanding applications requiring high-temperature resistance, like vulcanized rubber molding, mold creation, and high-temperature injection molding. Its versatility extends to improving the temperature resistance and precision of mixed resins.
Combining Forces for Superior 3D Printing
The synergy between the Elegoo Saturn 3 Ultra 12K and Siraya Tech Sculpt Ultra White Resin is unparalleled. This combination not only provides an excellent printing experience but also opens new avenues for creative and industrial applications that require high-temperature resistance and precision.
Discover the potential of high-temperature 3D printing and elevate your projects to new levels of professionalism and durability.
Explore more about Siraya Tech Sculpt Ultra White Resin at Siraya Tech, and find essential settings, MSDS, and TDS information at Print Settings, MSDS, and TDS. Embrace the future of 3D printing with Siraya Tech and Elegoo.
Critical Step: Post-Curing for Heat Resistance
High temperature resins do not reach their full thermal properties straight out of the printer. You must perform a "Thermal Post-Cure" (Baking) to cross-link the polymer chains fully.
| Step | Action | Why? |
|---|---|---|
| 1. Cleaning | Wash with 95%+ IPA or Ethanol. | Remove uncured resin before heating. |
| 2. UV Curing | Cure for 5-10 minutes under UV light. | Hardens the surface layer. |
| 3. Thermal Cure (Baking) | Bake at 80°C for 2 hours, then increase to 150°C for 1 hour. | Activates the high-temp properties (HDT 250°C). |
Printing Settings & Tips
High-temp resins are more viscous (thicker) than standard resins due to the ceramic additives. Follow these rules for success:
- Warm Up the Resin: Ensure your printing environment is at least 25°C - 30°C. Cold high-temp resin is like molasses and will cause print failures.
- Increase Lift Height: Use a lift height of 8mm+ to ensure the part separates cleanly from the FEP film.
- Heavy Supports: High-temp resin is heavy. Use "Heavy" or "Medium" supports with a contact depth of 0.5mm to prevent the part from ripping off the build plate.
Conclusion
With Siraya Tech Sculpt and a modern printer like the Elegoo Saturn 3 Ultra, you can now produce tooling that used to cost thousands of dollars in CNC machining.
Whether you are prototyping injection molds or creating heat shields, high-temp resin unlocks a new tier of engineering capabilities for your 3D printing workshop.
